Household Combustible Gas Detector JM-RTCO17-L

Carbon monoxide is produced when carbon-containing substances such as coal, petroleum, and wood burn in an oxygen-deficient environment. For example, carbon monoxide will be generated if the combustion is insufficient during the use of household heating equipment, kitchen stoves, industrial coal burning, etc. Carbon monoxide is a toxic gas, and exceeding a certain concentration will cause serious harm to human health. This product can monitor the concentration of carbon monoxide in the air and alarm in time when it exceeds the standard to prevent accidents.

Category :
Lora
Release time : 2026-02-13

Inquiry

Detailed Description

Main Product Functions:

Communication Method: LoRa Communication
Clear Working Indication Function: It has signal strength indication, signal transmission indication, and various product operation status indication functions.
Compatible with ceiling mounting and wall-mounted mounting methods.
Equipped with clock function and memory function.
1-Channel Relay Output

Product Technical Parameters:

Communication Method: LoRa Communication

Detected Gas: Carbon Monoxide (CO)

Alarm Concentration: 200x10-6 (Volume Fraction)

Measurement Range: 0-500x10-6 (Volume Fraction)

Operating Temperature: -10~+55℃

Mounting Method: Ceiling Mount / Wall Mount

Overall Dimension: Ф104*31.7mm

Power Consumption: ≤2W in Normal Monitoring State; ≤3W in Alarm State

Working Voltage: AC 220V/50Hz

Alarm Volume: >70dB (1 Meter in Front)

Sampling Method: Natural Diffusion
