Main Product Functions
- Adopts three detection technologies: smoke, temperature and temperature rise detection.
- Utilizes Zigbee communication mode.
- Powered by a high-performance CR123A lithium battery.
- Features a built-in pluggable card design for easy replacement at any time.
- Supports smoke concentration display function.
- Enables adaptive sensitivity adjustment with automatic regulation based on ambient noise.
- Clear working indication function: Equipped with signal strength indication, signal transmission indication and various product operating status indication functions.
- Robust self-test function: Includes self-test capabilities for module fault, Zigbee fault, signal transmission failure and platform communication fault.
- Flexible Tuya Cloud platform configuration function: Realizes remote setting of all product functions via the Tuya Cloud platform.
- Supports remote battery level reporting function.
- Allows remote setting of heartbeat interval.
- Enables remote mute function.
- Supports anti-tamper alarm function.
- Features low voltage alarm function.
- Obtains 3C certification from the Fire Product Conformity Assessment Center of the Ministry of Emergency Management.
- Issued with a test report by the National Fire Electronic Products Quality Inspection and Testing Center.
Technical Parameters
Communication Mode: Zigbee
Low Voltage Alarm Threshold: DC 2.7V
Operating Voltage: DC 3V
Quiescent Current: ≤10uA
Battery Specification: CR123A Lithium Battery
Alarm Temperature: ＞57℃ (Remotely Configurable)
Alarm Temperature Rise: ＞7℃/min (Remotely Configurable)
Operating Temperature: -10~+55℃
Operating Humidity: ＜95%RH
Overall Dimension: Ф105×51.3mm
Installation Method: Ceiling-mounted
