Main Product Functions
- Communication mode: Cat.1 all-network communication mode
- Built-in pluggable card for easy replacement
- Clear working indication function: Equipped with signal strength indication, signal transmission indication and various product operating status indication functions
- Robust self-test function: With self-test functions including module fault detection, Cat.1 card fault detection, signal transmission failure detection and platform communication fault detection
- Flexible cloud platform configuration function: Realizes remote setting of various product functions through the cloud platform
- With clock and memory functions
- With data export interface
- Supports connection with mechanical arm or solenoid valve
- Issued with a test report by the National Fire Electronic Products Quality Inspection and Testing Center
- Obtains the Fire Product Certification Certificate from the Fire Product Conformity Assessment Center of the Ministry of Emergency Management
- With the Network Access License for Telecommunication Equipment
- With the Type Approval Certificate for Radio Transmission Equipment
Technical Parameters
Communication Mode: Cat.1
Detected Gas: Natural Gas (CH₄)
Operating Voltage: AC220V/50Hz
Quiescent Current: ＜100mA
Alarm Sound Pressure: ≥70dB (1 meter in front)
Alarm Concentration: 8LEL±3LEL
Sampling Method: Natural Diffusion
Driving Capacity: 12V (200mA continuous for mechanical arm, 2A pulse for solenoid valve)
Operating Temperature: -10~+55℃
Operating Humidity: ＜95%RH
Installation Method: Wall-mounted / Ceiling-mounted
Dimension: 104×31.7mm
