Main Product Functions
- Communication method: LoRaWAN or LoRa custom protocol
- Built-in pluggable card for easy replacement.
- Battery specification: 1 CR14505 lithium-manganese battery.
- Alarm methods: button alarm, pull-cord alarm (optional function), under-voltage alarm, tamper alarm.
- Clear operation indication: signal strength indication, signal transmission indication, and various operating status indications of the product.
- Powerful self-test function: module fault detection, Cat.1 card fault detection, signal transmission failure detection, platform communication fault detection, etc.
- Flexible cloud platform configuration: various functions of the product can be remotely set through the cloud platform.
- Installation method: wall-mounted or standard 86-box installation.
Technical Parameters
- Communication: LoRaWAN or LoRa custom protocol
- Battery Voltage: DC 3V
- Operating Current: ≤460mA
- Operating Temperature: -10℃ ~ +55℃
- Dimensions: 93*93*30mm
- Alarm Trigger Methods: Button Alarm, Pull-Cord Alarm (Optional)
- Battery Specification: CR14505 Lithium-Manganese Battery
- Quiescent Current: ≤10μA
- Operating Humidity: ≤95%RH
- Installation Method: Wall-mounted / Standard 86-box
